- Place of Origin:China
- Type:Insulation Tape
- Material:PVC
- Application:High Voltage
- Brand Name:Liantu
- Rated Voltage:600V
- Tensile Strength:20N/CM
Product name :
High temperature free samples FR electrical insulating PVC adhesive tape
PVC Electrical Insulation Tape
Backing: PVC film
Adhesive: Nature Rubber, Pressure Sensitive Adhesive
Thickness: 0.10mm ~ 0.50mm
Width: 8mm ~ 1250mm
Length: 5m ~ 33m
Elongation at break: 150% ~ 220%
Tensile Strength: 20~30N/10mm
Peel Strength: 1.6N/10mm
Use temperature: 0~80°C,120°C
Use voltage: 600V
Characteristics
(1) PVC Electrical Tape for all wire and cable joints rated up to 600 V.
(2)Shijiazhuang Liantu has been manufacturing PVC tape over 15 years and providing more than 20 countries such as South East Asia, Middle East Asia, Europe, Latin America and African countries.
(3) Environmental friendly pressure sensitive adhesive, Unique glue-formulation and strong adhesive.
(4) insulating, water proof and excellent resistance to corrosion.
Details description
PVC tape rubber adhesive insulation tape UL,ROHS,CE /pvc electric tape /PVC insulation tape
Material: PVC | Use: sealilng cable | Adhesive Side: Single Sided |
Adhesive: Rubber | Adhesive Type: rubber glue | Feature: insulation |
Design Printing: offer Printing | Place of Origin: Shijiazhuang China (Mainland) | Brand Name: Liantu |
Model: PVC electrical insulation tape | Model Number: leto-008 | color: variety |
Material:
with soft polyvinyl chloride (PVC) film as the backing material, then coated rubber is solvent pressure sensitive glue.
It is Bright surface, insulation resistance electric appliances tape .
Specification:
1. Thickness:0.1mm-0.2mm
2. Peeling strength: 1.6-1.8(N/cm)
3. Tensile: 16-28(N/cm)
4. Tensile strength: 160%
5. Percentage elongation: 160%
6. Voltage breakdown: ≥6.5KV.
Features: color diversity, durable, high intensity, sticky tape take the gender is good.
Application: apply to electric wire, cable winding, transformer, power distribution equipment, automobile circuit, electrical engineering, household electrical, motor, capacitor, regulators etc all kinds of motor, electronic parts of the insulation fixed use.
About our PVC insulation tape:
PVC electric tape is made by smearing rubber like pressure-sensitive adhesive on PVC film (its backing material )and mangling them ,it has the feathers of insulation ,fire-resistance, high-voltage- resistance and cold resistance
It can be used in many electronic spare parts ,automobile wires, winding wires
