Electrical insulating tape PVC electrical insulation tape

• Product name:PVC electrical insulation tape on sale
• Color:black,white,red,green,blue,yellow
• Feature:High Temperature Resistance
• Usage:Insulation Protection
• Sample:accept trial
• Type:Insulation Tape
• Material:PVC
• Application:HIGH Voltage
• Place of Origin:CN;HEB
• Brand Name:Liantu
• Rated Voltage:600v

APPLICATIONS:

The PVC electrical insulating tape is a polyvinylchloride film manufactured from PVC made in a roller calendering way with the adhesive layer on one side, and cut on strips of the certain width. It is used in everyday household activities and as an insulation material during electrical works.

Composition:

PVC film

Adhesive layer on rubber base

Special Features:

1. Total thickness:0.13mm
2. Thickness of adhesive coat:0.12-0.15mm
3. Adhesion: ≥1.5N/cm
4. Tensile strength: ≥17 N/cm
5. Elongation: ≥160%
6. Voltage broken down: 8.0kv/mm
7. Working temperature range: from -10 to +80
8. Used for wrapping electrical wires and cables for insulation protective

Physical Parameter :
