- Place of Origin:CN;HEB
- Type:Insulation Tape
- Material:PVC
- Application:High Voltage
- Brand Name:leto
- Model Number:leto131
- Rated Voltage:4.5KV
- Tensile Strength:more than 160%
PVC electrical tape: OEM Service Offered Design Service Offered Buyer Label Offered
APPLICATIONS:
The PVC electrical insulating tape is a polyvinylchloride film manufactured from PVC made in a roller calendering way with the adhesive layer on one side, and cut on strips of the certain width. It is used in everyday household activities and as an insulation material during electrical works
Composition:
PVC film
Adhesive layer on rubber base
Special Features:
- Total thickness:0.13
- Thickness of adhesive coat:0.02mm
- Adhesion: ≥1.5N/cm
- Tensile strength: ≥17 N/cm
- Elongation: ≥160%
- Voltage broken down: 8.0kv/mm
- Working temperature range: from -30to +50c
Used for wrapping electrical wires and cables for insulation protective
Specification :
Items | Tape width | Tape length | Roll weight | Color |
301 | 19mm | 10m | 39g | Yellow-green |
302 | 19mm | 10m | 39g | Black |
303 | 19mm | 10m | 39g | Blue |
304 | 19mm | 10m | 39g | Red |
305 | 19mm | 10m | 39g | Yellow |
306 | 19mm | 10m | 39g | Green |
307 | 19mm | 10m | 39g | White |
308 | 19mm | 10m | 39g | Brown |
Individual package: each roll is packed by cellophane with a carton label which can make clients brand or logo as clients request.
Welcome OEM orders, tape thickness, Width, length and brand logo can made according to request
